20A with TR WR Self-test Socket For Home
20A with TR WR Self-test Socket For Home

20A with TR WR Self-test Socket For Home

Get Latest Price$4.3-4.6 /Piece/Pieces
Payment Type: T/T,Paypal
Incoterm: Ocean,Land,Air,Express
Min. Order: 1 Piece/Pieces
Transportation: Ocean,Land,Air,Express
Standard Classification of Plugs:
US
Product Attributes

Model No.WTST20

Brand3 Grace

warranty period3months-1year

Custom processingYes

place of originChina

Chassis styleWall Socket

Scope of applicationIndustrial, Commercial, Hospital, Residential / General-Purpose

GroundedGfci

CertificationUL

Operating Humidity30-93%

MaterialPC+copper

Current120V AC

Auto-Monitoring Function1s

OperatingTemperature-35℃ to 66℃

Trip Time0.0255s

Flamma bilityRated V-2 per UL 943

size105*44.6*42.6mm

Weight123.5g(without wallplate)

Packaging & Delivery
Selling Units: Piece/Pieces
Package Type: 1pc with color box, 10pcs with white box, 50pcs/carton or 100pcs/carton or Customized
Picture Example:
Product Description

A

4120279

-14-05

-06-07 (13)

-13

IUKL7IYH

JYUIOK

-07


Parameter TS15/20 TST15/20 WTST15/20 TST15L/20L
Amperage 15A/20A 15A/20A 15A/20A 15A/20A
Voltage 125V AC 125V AC 125V AC 125V AC
UL/CUL Listed
NEMA 5-15R/5-20R 5-15R/5-20R 5-15R/5-20R 5-15R/5-20R
Tamper-Resistant /
Weather-Resistant / / /
Applicable Standards UL943 Fifth Edition/UL498/UL1998
Trip Level 4~6mA ≤0.025s
Grounding Self-Grounding Cooper Clip Opitional
Face Material PC PC PC PC
Body Material PC+Copper PC+Copper PC+Copper PC+Copper
Operating Temperature -35℃ to +66℃
Flammability Rated V-2 per UL943
Warranty 2 Years
Color White/Ivory/Almond/Black/Brown or Customized

-02 (12)



Hot Tags: white 20amp tr wr self-test socket receptacle for american home, China, suppliers, manufacturers, factory, price, South America GFCI Outlet, Tamper Proof Gfci Breaker, Tamper Proof Gfci Outlets, 4 Gang Outlet Wall Plate, Gfci Protected Outlet, 220V White Gfci Outlet
Other
Company Overview
3Grace, Lishui Trimone Electrical Technology Co.,Ltd., is a manufacturer of ground-fault circuit interrupter(GFCI), USB charger, Switches, Receptacles, Wall plates and electrical accessories since 2001, We main export our products to United States, Canada, Mexico and Europe.Trimone covers an area of 20,000 square meters with more than 200 employees, housing a wide range of equipment capabilities catering to our production requirements, with an investment of RMB 50,000,000. Our annual sales revenue exceeds RMB 160 million. Trimone always value new products development and technological innovation. We take pride in our continuous functional improvement on our safe lock and reverse miswiring protection function than have acquired Chinese invention Patents and Utility Patents. In 2006, we invented a new version of GFCI with auto-monitoring and end-of-life indication function that complied with UL standard of the US and CUL standard of Canada. In 2015, we upgraded the GFCI with regular self-test function based on latest UL943 standard, which better protect the safety of our users. All our GFCI products are UL and CUL certified (No. E473989) and ETL certified( File No.5023317 ) which makes them eligible for United States and Canada, Mexico and Europe markets. In 2018, we got official United Stated Patent Named Circuit protection Device with automatic fault monitoring and detection function and United Stated Patent Named electrical circuit protection device for leakage current protection with the patent number 9906014 & 9906012. Moreover we got the Chinese Innovation Patent named A KIND OF MONITORING FUNCTION OPERATING FAULT CIRCUIT PROTECTION DEVICE with the patent No. ZL 2016 1 0339793.9 in Year 2018. We are located in the Shuige Economic Development Zone, Liandu District, Lishui City Zhejiang, 10KM from Lishui high-speed railway station. If you want to know more about us, welcome to visit us.
